mobile devices - Part 1

A year ago we looked at the legal and cybersecurity issues of allowing personal mobile devices—especially smartphones—on the plant floor. In this article we look at the advantages and technical considerations of deploying wireless devices on the plant floor. We especially look at user interfaces and their design, the handling of alarms, mobility issues and the future that brings AI and virtual reality/augmented reality to the world of mobile devices, freeing operators to accomplish tasks that weren’t easily possible with older, fixed HMIs.

Higher Performance Does Not Necessarily Make Technology Easier To Use

With the arrival of Wi-Fi 6 enabled hardware in late 2019 and Wi-Fi 7 scheduled to be ready in 2024—and 5G cellular systems having arrived in 2018-2019—the attraction to deploy wireless systems on the plant floor has become stronger than ever. Bandwidth is greater (albeit sometimes at a loss in range) and interference is generally less, resulting in improvements in data throughput. What this means in practice is the ability to transmit more sensor data and better-quality multimedia and video over a channel without buffering and stuttering. For example, with the recent replacement of an older Wi-Fi router, the extension to the 5 GHz band in Wi-Fi 6 allowed me to view nonstop, high-definition videos on my tablet, which wasn’t possible on 2.4 GHz—they would run for a few seconds before they would freeze, waiting for more data.

While all this improvement in performance is amazing, some apps on my tablet remain confusing, cumbersome and—quite frankly—difficult to use because they’re just not intuitive. Printing is a good example. While it’s easy to print on my Windows or Linux desktop from any application using the familiar CTRL + P keys, printing to the same network printers from my tablet is at best circuitous in nature and uses different printing apps to connect to an HP laser machine or Epson inkjet. Confusing is an understated term to explain printing from my tablet. Imagine having to shut down a packaging machine with such a counterintuitive system.

Fortunately, designers of industrial process control, MES and ERP software have intentionally designed user interfaces (UIs) that are not only intuitive, but place emphasis on the most important functions being upfront and easy to access and use. Web-based technology allows these UIs to resize automatically to fit the device in use—no matter the operating system. In addition, these interfaces are custom tailored for the specific personnel using them, that is to match their job functions.

According to Sanman Mehta, special projects engineer at IOTA Software Inc., forcing operators to switch between many UI systems can be inefficient and taxing in a fast-paced environment and introduces the possibility of human error and overload. “Our software is capable of supporting personnel in various roles, who could be working with the same machines and data but have different needs,” says Mehta. “For example, a rotating machinery engineer would be looking at certain mechanical key performance indicators (KPIs), which differ from those for which a process engineer would be interested. IOTA Vue software is elastic and can dynamically adjust to data and user demands, on any target UI device.”

What Apps Are Great For Mobile Devices?

“The ideal applications for wireless devices on the plant floor include HMI/UI for process monitoring and control, alarm notification, process KPIs, maintenance troubleshooting, VR/AR (virtual reality/augmented reality), and voice assistance (‘phone a friend’),” says Jim Vortherms, CRB senior director, control systems integration.

“Typically, we are observing applications primarily focused on the user interface, monitoring and control, as well as alarm notifications. The other potential uses are gaining popularity, partly driven by staffing shortages and knowledge loss due to retirements and attrition,” says Vortherms.

The next significant push appears to be in wireless maintenance and troubleshooting, providing maintenance technicians with access to troubleshooting guides, drawings, reference documents and remote assistance, adds Vortherms.

“Implemented systems often differ depending on the mobile platform utilized,” says Russell Weekley, manager, automation, Gray Solutions, a Gray Company and Control System Integrators Association (CSIA) member. “We commonly implement alarming notification and escalation for operations and plant-level KPIs and status for management needs delivered via smartphone devices. We have commonly been deploying HMIs utilizing tablet platforms to enable a mobile workforce with increased plant area control. The mobile technologies allow for fewer devices and more specific location-based securities to be implemented.”

From an application software provider’s point of view, such as ICONICS, the ideal applications for smartphones, notebooks and tablets on the plant floor involve getting machine statuses and information and, when warranted, fine-tuning or course-correcting machine performance via a setpoint change or initiating some type of maintenance work order based on the information, according to John Doto, director, professional services – Americas. For example, operators will be able to walk up to a machine and scan a QR code or dive into the app from their tablet to bring up live telemetry or real-time data for a particular machine status.

Also, these applications will allow operators to quickly look up documentation about the machine, like work orders or maintenance scheduling or information from other machines from other systems, adds Doto. Operators can also view trends of KPI metrics. And in the case of platforms with more advanced capabilities (like ICONICS CFSWorX), operators can be notified of an alarm based on their proximity to the problematic asset. For example, the maintenance technician closest to the machine would receive a notification to go to that machine to begin an investigation.

In last year’s article we mentioned various legal issues for not letting employees use their personal mobile equipment on the plant floor. But according to Maggie Slowik, IFS global industry director for manufacturing, there are other reasons for deploying company-issued devices. “The choice comes down to the user, nature of task, budget, preference, IT infrastructure, etc., but it’s important to ensure that all devices used on the plant floor are ruggedized or placed in protective cases to withstand the industrial environment. Within food plants, hygiene is obviously of paramount importance.” Therefore, it’s a good idea to keep employees’ personal devices in their lockers and away from food.

It’s important to remember that mobile devices do have limitations on the plant floor. INFOR offers a MES solution that has the ability to collect machine downtime, production count, scrap, inventory and quality data, according to Joe Russotti, senior director, sales. This type of data can be captured on tablets and PCs. People tend to use phones for looking at reports that are emailed. “Devices like phones are good for viewing data, not necessarily data entry,” says Russotti. “Touchscreen tablets have a larger screen than phones and are better suited for data entry for things like downtime reasons.”

Food processors provide mobile hardware when it is required for operations, says Eric Williams, digitalization group manager, Process and Data Automation (P&DA), a CSIA member. Most core control remains within structured HMIs and SCADA systems. Williams has many clients utilizing mobile add-ons to monitor remote equipment, either inside of a facility or of a larger enterprise—typically located away from facilities’ main processing equipment.

“Many of the systems we deploy are purpose-built for mobile,” adds Williams. “Quality systems that span many people and departments are a great example of this. Our Share to Act solutions for packaging line solutions also fall into this example as they have both multiple machines and a significant physical footprint, all coupled with a low operator count. Operators in these environments interact with not only the line controls but also the warehouse systems for raw ingredients and finished goods. They are also intertwined with maintenance functions, and our clients use them every day to access manuals, videos, and real-time connection to backend support from machine manufacturers.”

Optimizing the UI

It is very critical for end-users to access their data and screens in the appropriate format, be it a tablet or mobile device, says IOTA’s Mehta. Content builders should also be able to leverage the system in which they are building views, so that the end-user has the best experience without needing to switch between various configuration options.

Many of the most popular HMI applications today have the capability to resize the UI based on the device’s format, says CRB’s Vortherms. Many of these applications utilize a web interface or web-based technology, enabling dynamic resizing.

Typically, viewing relevant information for the operator is not an issue unless they are using a cell phone-sized screen. If there is a requirement to ensure that an operator sees specific job-related data on such a screen, a separate session with a dedicated application can be employed to manage the smaller screen size, adds Vortherms.

ICONICS calls dynamic resizing to fit the device and application “responsive design,” says Doto. Users can design graphics and dashboards to dynamically show and hide content based on real-time data, as well as the client device and the resolution. This technology can also resize and reposition visual aspects. For example, if you have a webpage on a laptop, you might see ten tiles across the page. But if you’re looking at this webpage on a mobile phone, the ten tiles might be placed in a single column that you can go through by scrolling down. Most personnel working on a plant floor have the necessary mobile phone/tablet savvy to understand and digest the reoriented visuals, so resizing to fit the mobile device is not an issue.

From a programming standpoint, UI developers should configure their graphics to meet the requirements of the application, says Doto. Of course, users can create a graphic that’s only legible on a laptop, but if their design didn’t make use of a responsive design approach, it won’t scale. When users build graphics with responsive design in mind, those applications very easily adapt to various resolutions and client devices and allow personnel to be mobile.

It is the type of application that determines which information should be displayed on which device, says Chiara Ponzellini, software commercialization product manager for Emerson’s controls and software business. For example, in a large food manufacturing company, in a control room, you can supervise the entire system, while at individual workstations, you can display details of the production line and machines. On pages viewed on mobile devices, only the most relevant data such as alarms or production efficiency data might be shown. All of this is possible through a single software solution and a unified development environment.

“For instance, one of our customers, a top Italian wine company producing over 300,000 wine bottles daily, wanted to show the status and efficiency of their bottling lines using pie charts on HMI Panels,” says Ponzellini. These easy-to-read graphics help operators keep an eye on how well machines like the depalletizer, filling machine, pasteurizer, labeling machine, packaging machine and palletizer are doing. The production line values in these charts show how efficiently the machines are working.

When processors use IFS on a mobile device, the page resizes and allows for the most pertinent information to be displayed, says Slowik. There should be no need to have separate versions for different devices. Each user will log onto the system with their user ID which will only allow them access to the transactions the system’s inbuilt security allows, (which is set by a systems administrator).

It’s important to remember that a small screen simply shouldn’t offer all the functionality of a dedicated HMI. Screens tend to become less graphically intense as they shrink, says P&DA’s Williams. “Furthermore, you must plan to remove controls for things that you don’t want operated via mobile, and this helps drive the operators to the equipment and local HMI for items that they should have eyes on before engaging for actual control.” End of Part 1
